STARTER MOTOR (MITSUBA)

STARTER MOTOR (DENSO) FOR HONDA INSIGHT DX 3 DOORS 5 SPEED MANUAL 2000

BREATHER TUBE

(1) 30201-PH9-004

Engine : 2000234 - zzzzzzzz

RING, SNAP (DENSO)

(2) 30202-RYE-003

Engine : 2000233 - zzzzzzzz

COLLAR, CLUTCH STOP

(3) 31200-PHM-G01

Engine : 2000234 - zzzzzzzz

MOTOR ASSY., STARTER (DS5E3) (1.0KW) (DENSO)

(4) 31201-PHM-G01

Engine : 2000234 - zzzzzzzz

HOUSING COMP., DRIVE SIDE

(5) 31202-PHM-G01

Engine : 2000234 - zzzzzzzz

ENDFRAME COMP., COMMUTATOR

(6) 31202-PM3-J01

Engine : 2000234 - zzzzzzzz

BOLT, THROUGH (DENSO)

(6) 31202-PM3-J01

Engine : 2000234 - zzzzzzzz

BOLT, THROUGH (DENSO)

(7) 31203-P3F-003

Engine : 2000234 - zzzzzzzz

LEVER, PINION DRIVE

(8) 31204-PHM-G01

Engine : 2000234 - zzzzzzzz

SWITCH ASSY., MAGNETIC

(9) 31205-RTA-003

Engine : 2000234 - zzzzzzzz

YOKE COMP.

(10) 31206-P3F-003

Engine : 2000234 - zzzzzzzz

ARMATURE COMP.

(11) 31207-PHM-G01

Engine : 2000234 - zzzzzzzz

CLUTCH COMP., OVERRUNNING

(12) 31208-P3F-003

Engine : 2000234 - zzzzzzzz

SCREW, PAN, 4MM

(12) 31208-P3F-003

Engine : 2000234 - zzzzzzzz

SCREW, PAN, 4MM

(13) 31213-PHM-G01

Engine : 2000234 - zzzzzzzz

SHAFT, DRIVE

(14) 31213-P64-N01

Engine : 2000234 - zzzzzzzz

COVER

(15) 31214-P3F-003

Engine : 2000234 - zzzzzzzz

GEAR ASSY., INTERNAL

(16) 31215-P3F-003

Engine : 2000234 - zzzzzzzz

GEAR COMP., PLANETARY

(16) 31215-P3F-003

Engine : 2000234 - zzzzzzzz

GEAR COMP., PLANETARY

(16) 31215-P3F-003

Engine : 2000234 - zzzzzzzz

GEAR COMP., PLANETARY

(17) 31216-RAA-003

Engine : 2000234 - zzzzzzzz

ABSORBER COMP., SHOCK

(18) 31217-P3F-003

Engine : 2000234 - zzzzzzzz

PLATE, SEAL

(19) 31218-P3F-003

Engine : 2000234 - zzzzzzzz

WASHER A

(20) 31219-P3F-003

Engine : 2000234 - zzzzzzzz

WASHER B

(21) 31220-PH9-004

Engine : 2000234 - zzzzzzzz

NUT, HEX., 8MM

(22) 31220-P3F-003

Engine : 2000234 - zzzzzzzz

WASHER C

(23) 31223-PA0-006

Engine : 2000234 - zzzzzzzz

NUT, HEX.

(23) 31223-PA0-006

Engine : 2000234 - zzzzzzzz

NUT, HEX.

(24) 31231-PHM-G01

Engine : 2000234 - zzzzzzzz

PLATE COMP., BRUSH HOLDER

(25) 94510-15000

Engine : 2000234 - zzzzzzzz

CIRCLIP, EXTERNAL, 15MM

	Part number	Description	Qty
# 1	30201-PH9-004 30201PH9004 30201PH9004	RING, SNAP (DENSO)	2,23 €(1,91 £)
# 2	30202-P3F-003 30202-RYE-003 30202P3F003	COLLAR, CLUTCH STOP	8,99 €(7,69 £)
# 3	31200-PHM-G01 31200PHMG01 31200PHMG01	MOTOR ASSY., STARTER (DS5E3) (1.0KW) (DENSO)	Not available	0,00 €(0,00 £)
# 4	31201-PHM-G01 31201PHMG01 31201PHMG01	HOUSING COMP., DRIVE SIDE	Not available	0,00 €(0,00 £)
# 5	31202-PHM-G01 31202PHMG01 31202PHMG01	ENDFRAME COMP., COMMUTATOR	Not available	0,00 €(0,00 £)
# 6	31202-PM3-J01 31202PM3J01 31202PM3J01	BOLT, THROUGH (DENSO)	3,68 €(3,15 £)
# 7	31203-P3F-003 31203P3F003 31203P3F003	LEVER, PINION DRIVE	Not available	0,00 €(0,00 £)
# 8	31204-PHM-G01 31204PHMG01 31204PHMG01	SWITCH ASSY., MAGNETIC	Not available	0,00 €(0,00 £)
# 9	31205-P3F-003 31205-RTA-003 31205P3F003	YOKE COMP.	254,40 €(217,61 £)
# 10	31206-P3F-003 31206P3F003 31206P3F003	ARMATURE COMP.	Not available	0,00 €(0,00 £)
# 11	31207-PHM-G01 31207PHMG01 31207PHMG01	CLUTCH COMP., OVERRUNNING	Not available	0,00 €(0,00 £)
# 12	31208-P3F-003 31208P3F003 31208P3F003	SCREW, PAN, 4MM	2,02 €(1,73 £)
# 13	31213-PHM-G01 31213PHMG01 31213PHMG01	SHAFT, DRIVE	Not available	0,00 €(0,00 £)
# 14	31213-P64-N01 31213P64N01 31213P64N01	COVER	4,48 €(3,83 £)
# 15	31214-P3F-003 31214P3F003 31214P3F003	GEAR ASSY., INTERNAL	69,25 €(59,24 £)
# 16	31215-P3F-003 31215P3F003 31215P3F003	GEAR COMP., PLANETARY	44,92 €(38,42 £)
# 17	31216-P3F-003 31216-RAA-003 31216P3F003	ABSORBER COMP., SHOCK	20,59 €(17,61 £)
# 18	31217-P3F-003 31217P3F003 31217P3F003	PLATE, SEAL	10,51 €(8,99 £)
# 19	31218-P3F-003 31218P3F003 31218P3F003	WASHER A	5,22 €(4,47 £)
# 20	31219-P3F-003 31219P3F003 31219P3F003	WASHER B	5,22 €(4,47 £)
# 21	31220-PH9-004 31220PH9004 31220PH9004	NUT, HEX., 8MM	3,63 €(3,11 £)
# 22	31220-P3F-003 31220P3F003 31220P3F003	WASHER C	6,57 €(5,62 £)
# 23	31223-PA0-006 31223PA0006 31223PA0006	NUT, HEX.	3,63 €(3,11 £)
# 24	31231-PHM-G01 31231PHMG01 31231PHMG01	PLATE COMP., BRUSH HOLDER	Not available	0,00 €(0,00 £)
# 25	94510-15000 9451015000 9451015000	CIRCLIP, EXTERNAL, 15MM	3,55 €(3,04 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the STARTER MOTOR (DENSO) of your Honda of 2000. Let us know if you have any questions.
