FRONT SEAT COMPONENTS (L.)(RH) RH

FRONT SEAT COMPONENTS (R.)(RH) FOR HONDA LEGEND COUPE LEGEND 2 DOORS 4 SPEED AUTOMATIC 1991

REAR SEAT

(1) 04815-SP1-000

CABLE SET, SEATBACK WALK-IN (DRIVER SIDE)

(2) 35950-SP0-J01ZD

Color of the spare part: CREAM IVORY

SWITCH ASSY., R. POWER SEAT *Y31L*

(2) 35950-SP0-J02ZE

Color of the spare part: EXCEL CHARCOAL

SWITCH ASSY., R. POWER SEAT *NH178L*

(3) 35951-SP0-J22ZC

Color of the spare part: CREAM IVORY

KNOB A *Y31L*

(3) 35951-SP0-J22ZD

Color of the spare part: EXCEL CHARCOAL

KNOB A *NH178L*

(4) 35952-SP0-A12ZD

Color of the spare part: CREAM IVORY

KNOB B *Y31L*

(4) 35952-SP0-A12ZE

Color of the spare part: EXCEL CHARCOAL

KNOB B *NH178L*

(5) 35953-SP0-J21ZD

Color of the spare part: CREAM IVORY

KNOB C *Y31L*

(5) 35953-SP0-J21ZE

Color of the spare part: EXCEL CHARCOAL

KNOB C *NH178L*

(6) 81117-S47-003

BUSH, NYLON (TS TECH)

(7) 77209-SB0-003

WASHER, NYLON

(8) 77517-SA5-014

CAP, SLIDE ADJUSTER

(9) 81110-SP1-E22

DEVICE COMP., R. FR. SEAT

(19) 81228-SP1-023

BOX ASSY., POWER SEAT CONTROL

(20) 81237-SP0-J21ZD

Color of the spare part: CREAM IVORY

GARNISH, R. FR. SEAT CUSHION *Y31L*

(20) 81237-SP0-J21ZE

Color of the spare part: EXCEL CHARCOAL

GARNISH, R. FR. SEAT CUSHION *NH178L*

(22) 81311-SP1-J00

CORD A, R. POWER SEAT

(23) 81314-SP1-J00

PROTECTOR, R. WIRE HARNESS

(24) 81401-SP1-003

REACHER ASSY., R.

(36) 90649-SC2-003

BAND, WIRE HARNESS (NATURAL) (150MM)

(37) 90672-SA0-003

STRAP, CABLE, 118MM (BLACK)

(37) 90672-SA0-003

STRAP, CABLE, 118MM (BLACK)

(37) 90672-SA0-003

STRAP, CABLE, 118MM (BLACK)

(38) 91545-SE0-003

CLIP ASSY., 8MM

(39) 91547-P45-003

BAND, WIRE HARNESS (BLUE) (123.5MM)

(39) 91547-P45-003

BAND, WIRE HARNESS (BLUE) (123.5MM)

(40) 91567-SE0-003

BAND, WIRE HARNESS (WHITE) (93.5MM)

(40) 91567-SE0-003

BAND, WIRE HARNESS (WHITE) (93.5MM)

(41) 93403-0602008

BOLT-WASHER, 6X20

(42) 93405-1002008

BOLT-WASHER, 10X20

(42) 93405-1002008

BOLT-WASHER, 10X20

(43) 93402-1002208

BOLT-WASHER, 10X22

(43) 93402-1002208

BOLT-WASHER, 10X22

(43) 93402-1002208

BOLT-WASHER, 10X22

(44) 93492-1002708

BOLT-WASHER, 10X27

(44) 93492-1002708

BOLT-WASHER, 10X27

(45) 93893-0502508

SCREW-WASHER, 5X25

(46) 93903-24120

SCREW, TAPPING, 4X8

(47) 94070-08080

NUT-WASHER, 8MM

(48) 94101-08700

WASHER, PLAIN, 8MM

	Part number	Description	Qty
# 1	04815-SP1-000 04815SP1000 04815SP1000	CABLE SET, SEATBACK WALK-IN (DRIVER SIDE)	Not available	0,00 €(0,00 £)
# 2	35950-SP0-J01ZD 35950SP0J01ZD 35950SP0J01ZD	SWITCH ASSY., R. POWER SEAT Y31L	Not available	0,00 €(0,00 £)
# 2	35950-SP0-J01ZE 35950SP0J01ZE	SWITCH ASSY., R. POWER SEAT NH178L	Not available	0,00 €(0,00 £)
# 3	35951-SP0-J21ZC 35951SP0J21ZC	KNOB A Y31L	Not available	0,00 €(0,00 £)
# 3	35951-SP0-J21ZD 35951SP0J21ZD	KNOB A NH178L	Not available	0,00 €(0,00 £)
# 4	35952-SP0-A11ZD 35952SP0A11ZD	KNOB B Y31L	Not available	0,00 €(0,00 £)
# 4	35952-SP0-A11ZE 35952SP0A11ZE	KNOB B NH178L	Not available	0,00 €(0,00 £)
# 5	35953-SP0-J21ZD 35953SP0J21ZD 35953SP0J21ZD	KNOB C Y31L	Not available	0,00 €(0,00 £)
# 5	35953-SP0-J21ZE 35953SP0J21ZE 35953SP0J21ZE	KNOB C NH178L	Not available	0,00 €(0,00 £)
# 6	77208-SA5-003 81117-S47-003 77208SA5003	BUSH, NYLON (TS TECH)	5,61 €(4,80 £)
# 7	77209-SB0-003 77209SB0003 77209SB0003	WASHER, NYLON	4,57 €(3,91 £)
# 8	77517-SA5-014 77517SA5014 77517SA5014	CAP, SLIDE ADJUSTER	6,29 €(5,39 £)
# 9	81110-SP1-E21 81110SP1E21	DEVICE COMP., R. FR. SEAT	Not available	0,00 €(0,00 £)
# 19	81228-SP1-003 81228SP1003	BOX ASSY., POWER SEAT CONTROL	Not available	0,00 €(0,00 £)
# 20	81237-SP0-J21ZD 81237SP0J21ZD 81237SP0J21ZD	GARNISH, R. FR. SEAT CUSHION Y31L	Not available	0,00 €(0,00 £)
# 20	81237-SP0-J21ZE 81237SP0J21ZE 81237SP0J21ZE	GARNISH, R. FR. SEAT CUSHION NH178L	Not available	0,00 €(0,00 £)
# 22	81311-SP1-J00 81311SP1J00 81311SP1J00	CORD A, R. POWER SEAT	Not available	0,00 €(0,00 £)
# 23	81314-SP1-J00 81314SP1J00 81314SP1J00	PROTECTOR, R. WIRE HARNESS	Not available	0,00 €(0,00 £)
# 24	81401-SP1-003 81401SP1003 81401SP1003	REACHER ASSY., R.	Not available	0,00 €(0,00 £)
# 36	90649-SC2-003 90649SC2003 90649SC2003	BAND, WIRE HARNESS (NATURAL) (150MM)	7,41 €(6,35 £)
# 37	90672-SA0-003 90672SA0003 90672SA0003	STRAP, CABLE, 118MM (BLACK)	6,92 €(5,93 £)
# 38	91545-SE0-003 91545SE0003 91545SE0003	CLIP ASSY., 8MM	4,96 €(4,25 £)
# 39	91547-SF4-003 91547SF4003	BAND, WIRE HARNESS (BLUE) (123.5MM)	Not available	0,00 €(0,00 £)
# 40	91567-SE0-003 91567SE0003 91567SE0003	BAND, WIRE HARNESS (WHITE) (93.5MM)	9,51 €(8,14 £)
# 41	93403-0602008 934030602008 934030602008	BOLT-WASHER, 6X20	1,00 €(0,86 £)
# 42	93405-1002008 934051002008 934051002008	BOLT-WASHER, 10X20	Not available	0,00 €(0,00 £)
# 43	93492-1002208 934921002208	BOLT-WASHER, 10X22	Not available	0,00 €(0,00 £)
# 44	93492-1002708 934921002708 934921002708	BOLT-WASHER, 10X27	Not available	0,00 €(0,00 £)
# 45	93893-0502508 938930502508 938930502508	SCREW-WASHER, 5X25	1,04 €(0,89 £)
# 46	93903-24120 9390324120 9390324120	SCREW, TAPPING, 4X8	0,57 €(0,49 £)
# 47	94070-08080 9407008080 9407008080	NUT-WASHER, 8MM	0,86 €(0,74 £)
# 48	94101-08700 9410108700 9410108700	WASHER, PLAIN, 8MM	0,56 €(0,48 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FRONT SEAT COMPONENTS (R.)(RH) of your Honda of 1991. Let us know if you have any questions.
