AIR CONDITIONER (UNIT) (LH) LH

AIR CONDITIONER (HOSES / PIPES)(LH) FOR HONDA LEGEND 2.5 V6 4 DOORS 4 SPEED AUTOMATIC 1987

ATF COOLER

Item numbers

RUBBER, MOUNTING

31401-659-003 31401659003

Not available

VALVE, SAFETY

38641-671-013 38641671013

Not available

O-RING, 8MM

38646-SA5-003 38646SA5003

Not available

O-RING (1/2")

38647-692-660

80872-SL0-900

3,53 €(3,07 £)

Unit Price Excl Tax

O-RING (5/8")

38648-692-660

80871-SL0-900

6,55 €(5,70 £)

Unit Price Excl Tax

CLAMP, SUCTION PIPE

38673-SB0-000 38673SB0000

Not available

CLAMP, SUCTION HOSE

38677-SB2-671 38677SB2671

Not available

SUB CORD, AIR CONDITIONER

38710-SG9-E00 38710SG9E00

Not available

BRACKET, AIR CONDITIONER RELAY

39451-SD4-000 39451SD4000

Not available

RELAY ASSY., POWER (4P) (058700-1170) (DENSO)

39798-SE0-003

Not available

HOSE COMP., SUCTION

80310-SD4-A01 80310SD4A01

Not available

HOSE COMP., DISCHARGE

80315-SG9-E00

Not available

PIPE, DISCHARGE

80316-SD4-003

Not available

PIPE A, RECEIVER

80323-SG9-G00

Not available

PIPE A, CONDENSER

80325-SD4-003 80325SD4003

Not available

TANK ASSY., RECEIVER

80340-SD4-003

Not available

CLAMP, DISCHARGE PIPE

80352-SD4-000 80352SD4000

Not available

CLAMP, DISCHARGE HOSE

80360-SD4-003 80360SD4003

Not available

CLAMP, DISCHARGE HOSE

80360-SG9-E01 80360SG9E01

Not available

BRACKET, SUCTION PIPE

80361-SD4-A00 80361SD4A00

Not available

HOLDER, DISCHARGE HOSE

80361-SE0-000 80361SE0000

Not available

STAY, DISCHARGE PIPE

80365-SD4-003

Not available

CLAMP, RECEIVER PIPE

80370-SD4-000 80370SD4000

Not available

GROMMET, SUCTION PIPE

80380-SE0-000

Not available

GROMMET, LIQUID PIPE

80381-SE0-000

Not available

SWITCH, PRESSURE

80440-SD4-013

Not available

SWITCH, DUAL PRESSURE

80441-SD4-003 80441SD4003

Not available

SUB HARNESS, PRESSURE SWITCH

80445-SD4-010 80445SD4010

Not available

SCREW, TAPPING, 6X20

90141-SD4-000

90155-SE0-003

4,41 €(3,83 £)

Unit Price Excl Tax

SCREW, TAPPING, 6X20

90155-SE0-003 90155SE0003

4,41 €(3,83 £)

Unit Price Excl Tax

TIE, HARNESS

90669-SG2-E00

Not available

GROMMET, FUEL TUBE (BLACK)

90854-SA0-680 90854SA0680

Not available

COLLAR, OIL PUMP

90854-671-000 90854671000

Not available

GROMMET, SCREW, 6MM

91619-SA5-000

Not available

BOLT-WASHER, 6X12

93493-0601208

93403-0601208

1,02 €(0,89 £)

Unit Price Excl Tax

BOLT-WASHER, 6X20

93493-0602008

93403-0602008

1,02 €(0,89 £)

Unit Price Excl Tax

NUT, HEX., 6MM (PACK OF 10)

94001-060000S

94001-062000S

9,70 €(8,43 £)

Unit Price Excl Tax

BOLT, FLANGE, 8X30

95830-0803018 958300803018

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the AIR CONDITIONER (HOSES/PIPES)(LH) of your Honda of 1987. Let us know if you have any questions.
