GLOVE BOX

SLIDING ROOF (1) FOR HONDA PRELUDE 2.0EX 2 DOORS 4 SPEED AUTOMATIC 1988

SLIDING ROOF (2)

(1) 15707-634-000

CLIP, OIL DRAIN TUBE

(2) 18534-634-670

CLIP, AIR HOSE, 16MM

(2) 18534-634-670

CLIP, AIR HOSE, 16MM

(4) 70050-SF1-000

TUBE, FR. DRAIN (SUNROOF)

(6) 70052-SF1-000

VALVE, FR. SLIDE ROOF DRAIN

(7) 70060-SF1-000

TUBE, RR. DRAIN (SUNROOF)

(7) 70060-SF1-000

TUBE, RR. DRAIN (SUNROOF)

(8) 70062-SF1-000

VALVE, R. RR. DRAIN (SUNROOF)

(9) 70080-SG0-000

SEAL, SUNROOF FRAME

(10) 70090-SG0-000

STOPPER, SUNSHADE

(11) 70100-SF1-000

FRAME COMP., SUNROOF

(12) 70173-SA5-920

VALVE, RR. SLIDE ROOF DRAIN

(13) 70176-693-920

VALVE, SLIDE ROOF INNER DRAIN

(13) 70176-693-920

VALVE, SLIDE ROOF INNER DRAIN

(14) 70200-SF1-505

GLASS ASSY., ROOF

(15) 70214-SF1-000

CUSHION, FR. GLASS HOLDER

(16) 70620-SF1-000

COVER, R. STAY (SUNROOF)

(17) 93500-050080G

SCREW, STAY COVER

(18) 70625-SF1-000

COVER, L. STAY (SUNROOF)

(19) 71824-SD2-305ZB

Color of the spare part: LOFTY GRAY

TRIM, FR. ROOF *NH91L*

(19) 71824-SA6-010ZP

Color of the spare part: COAST SAND

TRIM, FR. ROOF *YR98L*

(20) 71871-SF1-000ZA

Color of the spare part: LOFTY GRAY

CAP, ROOF LINING *NH91L*

(20) 71871-SF1-000ZD

Color of the spare part: COAST SAND

CAP, ROOF LINING *YR98L*

(21) 71983-SF1-000

PLATE COMP., SUN SHADE

(22) 71986-692-920

CAP, STAY COVER

(23) 83200-SF1-J11ZA

Color of the spare part: LOFTY GRAY

LINING ASSY., ROOF *NH91L*

(23) 83200-SF1-A04ZD

Color of the spare part: COAST SAND

LINING ASSY., ROOF *YR98L*

(23) 83200-SF1-J11ZA

Engine : 00000000 - 0C000093
Color of the spare part: LOFTY GRAY

LINING ASSY., ROOF *NH91L*

(23) 83200-SF1-J11ZD

Engine : 00000000 - 0C000093
Color of the spare part: COAST SAND

LINING ASSY., ROOF *YR98L*

(23) 83200-SF1-J11ZA

Engine : 0C024478 - zzzzzzzz
Color of the spare part: LOFTY GRAY

LINING ASSY., ROOF *NH91L*

(23) 83200-SF1-J11ZD

Engine : 0C024478 - zzzzzzzz
Color of the spare part: COAST SAND

LINING ASSY., ROOF *YR98L*

(24) 83210-SF1-A03ZA

Engine : 00000000 - 0C000093
Color of the spare part: LOFTY GRAY

SUNSHADE ASSY. *NH91L*

(24) 83210-SF1-A03ZD

Engine : 00000000 - 0C000093
Color of the spare part: COAST SAND

SUNSHADE ASSY. *YR98L*

(24) 83210-SF1-A03ZA

Color of the spare part: LOFTY GRAY

SUNSHADE ASSY. *NH91L*

(24) 83210-SF1-A03ZD

Color of the spare part: COAST SAND

SUNSHADE ASSY. *YR98L*

(24) 83210-SF1-A03ZA

Engine : 0C010118 - zzzzzzzz
Color of the spare part: LOFTY GRAY

SUNSHADE ASSY. *NH91L*

(24) 83210-SF1-A03ZD

Engine : 0C010118 - zzzzzzzz
Color of the spare part: COAST SAND

SUNSHADE ASSY. *YR98L*

(25) 83213-SF1-000

WASHER COMP., PLATE

(26) 83214-SF1-000ZA

Color of the spare part: LOFTY GRAY

HANDLE *NH91L*

(26) 83214-SF1-000ZE

Color of the spare part: COAST SAND

HANDLE *YR98L*

(27) 83220-SF1-030ZB

Engine : 00000000 - 0C000965
Color of the spare part: LOFTY GRAY

TRIM, ROOF *NH91L*

(28) 93913-14480

SCREW, TAPPING, 4X16

(29) 90666-689-013C2

Engine : 00000000 - 0C017935
Color of the spare part: LOFTY GRAY

CLIP, TRIM, 6MM *NH91L*

(29) 90666-689-013C5

Engine : 00000000 - 0C017935
Color of the spare part: COAST SAND

CLIP, TRIM, 6MM *YR98L*

(29) 90673-SE0-003

Engine : 0C017936 - zzzzzzzz

CLIP, ROOF LINING

(30) 91504-SE3-920

CLIP, SLIDE ROOF DRAIN TUBE

(31) 93405-0601208

BOLT-WASHER, 6X12

	Part number	Description	Qty
# 1	15707-634-000 15707634000 15707634000	CLIP, OIL DRAIN TUBE	3,06 €(2,63 £)
# 2	18534-634-670 18534634670 18534634670	CLIP, AIR HOSE, 16MM	3,38 €(2,91 £)
# 4	70050-SF1-000 70050SF1000 70050SF1000	TUBE, FR. DRAIN (SUNROOF)	Not available	0,00 €(0,00 £)
# 6	70052-SF1-000 70052SF1000 70052SF1000	VALVE, FR. SLIDE ROOF DRAIN	Not available	0,00 €(0,00 £)
# 7	70060-SF1-000 70060SF1000 70060SF1000	TUBE, RR. DRAIN (SUNROOF)	Not available	0,00 €(0,00 £)
# 8	70062-SF1-000 70062SF1000 70062SF1000	VALVE, R. RR. DRAIN (SUNROOF)	Not available	0,00 €(0,00 £)
# 9	70080-SG0-000 70080SG0000 70080SG0000	SEAL, SUNROOF FRAME	Not available	0,00 €(0,00 £)
# 10	70090-SG0-000 70090SG0000 70090SG0000	STOPPER, SUNSHADE	Not available	0,00 €(0,00 £)
# 11	70100-SF1-000 70100SF1000 70100SF1000	FRAME COMP., SUNROOF	Not available	0,00 €(0,00 £)
# 12	70173-SA5-920 70173SA5920 70173SA5920	VALVE, RR. SLIDE ROOF DRAIN	Not available	0,00 €(0,00 £)
# 13	70176-693-920 70176693920 70176693920	VALVE, SLIDE ROOF INNER DRAIN	Not available	0,00 €(0,00 £)
# 14	70200-SF1-000 70200SF1000	GLASS ASSY., ROOF	Not available	0,00 €(0,00 £)
# 15	70214-SF1-000 70214SF1000 70214SF1000	CUSHION, FR. GLASS HOLDER	Not available	0,00 €(0,00 £)
# 16	70620-SF1-000 70620SF1000 70620SF1000	COVER, R. STAY (SUNROOF)	Not available	0,00 €(0,00 £)
# 17	70621-SG0-000 93500-050080G 70621SG0000	SCREW, STAY COVER	0,69 €(0,59 £)
# 18	70625-SF1-000 70625SF1000 70625SF1000	COVER, L. STAY (SUNROOF)	Not available	0,00 €(0,00 £)
# 19	71824-SA6-010ZL 71824SA6010ZL	TRIM, FR. ROOF NH91L	Not available	0,00 €(0,00 £)
# 19	71824-SA6-010ZP 71824SA6010ZP 71824SA6010ZP	TRIM, FR. ROOF YR98L	Not available	0,00 €(0,00 £)
# 20	71871-SF1-000ZA 71871SF1000ZA 71871SF1000ZA	CAP, ROOF LINING NH91L	Not available	0,00 €(0,00 £)
# 20	71871-SF1-000ZD 71871SF1000ZD 71871SF1000ZD	CAP, ROOF LINING YR98L	Not available	0,00 €(0,00 £)
# 21	71983-SF1-000 71983SF1000 71983SF1000	PLATE COMP., SUN SHADE	Not available	0,00 €(0,00 £)
# 22	71986-692-920 71986692920 71986692920	CAP, STAY COVER	Not available	0,00 €(0,00 £)
# 23	83200-SF1-E00ZA 83200SF1E00ZA	LINING ASSY., ROOF NH91L	Not available	0,00 €(0,00 £)
# 23	83200-SF1-E00ZD 83200SF1E00ZD	LINING ASSY., ROOF YR98L	Not available	0,00 €(0,00 £)
# 23	83200-SF1-J10ZA 83200SF1J10ZA	LINING ASSY., ROOF NH91L	Not available	0,00 €(0,00 £)
# 23	83200-SF1-J10ZD 83200SF1J10ZD	LINING ASSY., ROOF YR98L	Not available	0,00 €(0,00 £)
# 23	83200-SF1-J11ZA 83200SF1J11ZA 83200SF1J11ZA	LINING ASSY., ROOF NH91L	Not available	0,00 €(0,00 £)
# 23	83200-SF1-J11ZD 83200SF1J11ZD 83200SF1J11ZD	LINING ASSY., ROOF YR98L	Not available	0,00 €(0,00 £)
# 24	83210-SF1-010ZA 83210SF1010ZA	SUNSHADE ASSY. NH91L	Not available	0,00 €(0,00 £)
# 24	83210-SF1-010ZD 83210SF1010ZD	SUNSHADE ASSY. YR98L	Not available	0,00 €(0,00 £)
# 24	83210-SF1-A00ZA 83210SF1A00ZA	SUNSHADE ASSY. NH91L	Not available	0,00 €(0,00 £)
# 24	83210-SF1-A00ZD 83210SF1A00ZD	SUNSHADE ASSY. YR98L	Not available	0,00 €(0,00 £)
# 24	83210-SF1-A03ZA 83210SF1A03ZA 83210SF1A03ZA	SUNSHADE ASSY. NH91L	Not available	0,00 €(0,00 £)
# 24	83210-SF1-A03ZD 83210SF1A03ZD 83210SF1A03ZD	SUNSHADE ASSY. YR98L	Not available	0,00 €(0,00 £)
# 25	83213-SF1-305 83213SF1305	WASHER COMP., PLATE	Not available	0,00 €(0,00 £)
# 26	83214-SF1-000ZE 83214SF1000ZE 83214SF1000ZE	HANDLE YR98L	Not available	0,00 €(0,00 £)
# 26	83214-SF1-000ZA 83214SF1000ZA 83214SF1000ZA	HANDLE NH91L	Not available	0,00 €(0,00 £)
# 27	83220-SF1-010ZA 83220SF1010ZA	TRIM, ROOF NH91L	Not available	0,00 €(0,00 £)
# 28	90102-SA4-000 93913-14480 90102SA4000	SCREW, TAPPING, 4X16	0,63 €(0,54 £)
# 29	90666-689-013C2 90666689013C2 90666689013C2	CLIP, TRIM, 6MM NH91L	Not available	0,00 €(0,00 £)
# 29	90666-689-013C5 90666689013C5 90666689013C5	CLIP, TRIM, 6MM YR98L	Not available	0,00 €(0,00 £)
# 29	90673-SE0-003 90673SE0003 90673SE0003	CLIP, ROOF LINING	Not available	0,00 €(0,00 £)
# 30	91504-SE3-920 91504SE3920 91504SE3920	CLIP, SLIDE ROOF DRAIN TUBE	3,97 €(3,41 £)
# 31	93495-0601208 93405-0601208 934950601208	BOLT-WASHER, 6X12	1,00 €(0,86 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the SLIDING ROOF (1) of your Honda of 1988. Let us know if you have any questions.
